Description

Boss SD1W Waza Craft Custom Super Overdrive Pedal

The Boss SD-1W Waza Craft Custom Super Overdrive Pedal takes on the mammoth task of attempting to refine and improve the near-perfect original SD-1 design. The original SD-1 has earned its legendary status based on 40 years of peerless performance thanks to one clever feature- asymmetric clipping. Most overdrive pedals clip symmetrically giving a slightly thinner sound, that’s because asymmetrical clipping creates more harmonic overtones. This gives a richer, thicker sound, overall. This design feature is patented by Boss (Roland) meaning the SD-1s are the only overdrive pedal that can offer this incredible tonal secret.

SD-1+

The SD-1 all grown up. With the Boss SD-1W Waza Craft Custom Super Overdrive Pedal, Boss have refined the original design and spared no expense creating the most deluxe overdrive pedal possible. Firstly, all the internal circuitry has been switched to the most premium component choices available with 100% discrete circuitry preferred to op amps- no shortcuts here. This gives the tone additional purity while also making the sound more full, especially in the treble regions where the response is thicker and more resonant. The Custom modes makes slight changes but the core tone is similar. Generally more rounded and slightly beefier, there’s still a midrange bump and a drop in the bottom end, but it’s less pronounced. The higher you crank the gain, the more pronounced these changes become. Get your hands on the most comprehensive Super Overdrive ever.

Boss SD1W Waza Craft Custom Super Overdrive Pedal Features:

• Special edition Waza Craft pedal delivers the ultimate BOSS tone experience
• Premium sound based on the legendary SD-1 Super Overdrive
• Newly revised, all-analog discrete amplifier circuit
• Standard and Custom sound modes
• Highly responsive to picking dynamics and volume changes
• BOSS five-year warranty

Boss SD1W Waza Craft Custom Super Overdrive Pedal Specifications:

• Nominal Input Level: -20 dBu
• Input Impedance: 1 M ohm
• Nominal Output Level: -20 dBu
• Output Impedance: 1 k ohm
• Recommended Load Impedance: 10 k ohms or greater
• Controls:
  • Pedal switch
  • Mode switch
  • LEVEL knob
  • TONE knob
  • DRIVE knob
• Indicator: CHECK indicator (Serves also as battery check indicator)
• Connectors:
  • INPUT jack
  • OUTPUT jack
  • DC IN jack
• Power Supply:
  • Alkaline battery (9 V, 6LR61) or Carbon-zinc battery (9 V, 6F22)
  • AC adaptor (sold separately)
• Current Draw: 15 mA
• Accessories:
  • Owner’s Manual
  • Leaflet (“USING THE UNIT SAFELY,” “IMPORTANT NOTE,” and “Information”)
  • Carbon-zinc battery (9 V, 6F22)
• Option (sold separately): AC adaptor (PSA series)
